Electrical equipment

The 85x85x45 mm Watertight Junction Box with snap-on lid is perfect for installations in all conditions.

It incorporates 7 cones with a maximum dimension of 25 mm, making connections easy and safe. Manufactured in accordance with UNE-EN 60670-1:2006 and UNE 20324:1993. The 85x85x45 mm Watertight Junction Box with snap-on cover is designed to be practical and durable. It has IP55 protection and its impact resistance index is IK07. It is also fire resistant (glow wire at 650º). Operating temperature: -25ºC (+60ºC).

With the Weatherproof Junction Box 85x85x45 mm with snap-on lid on our DESIGN-LED online site, you can perfectly protect all types of electrical junctions.

• Dimensions:
• Height (mm): 80
• Width (mm) : 66
• Length (mm) : 45

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

The 113x113x60 mm Watertight Junction Box lets you make connections and junctions both indoors and outdoors.

This box incorporates 7 cones of up to 25mm for routing cabling. It has been manufactured in accordance with standards UNE-EN 60670-1:2006 and UNE 20324:1993. The 113x113x60 mm Watertight Junction Box has a ¼ turn screw closure with a hermetic lid. It is designed to be practical and durable. With IP55 protection and its shock resistance rating is IK07. It is also fire resistant (glow wire at 650º). Operating temperature : -25ºC (+60ºC).

With the Weatherproof Junction Box 85x85x45 mm with snap-on lid on our DESIGN-LED online site, you can perfectly protect all types of electrical junction.

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

• Dimensions:
• Height (mm): 200
• Width (mm) : 112
• Length (mm): 112
• Number of modules: 4

DB series switching devices, which meet the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

• Dimensions:
• Height (mm): 220
• Width (mm) : 102
• Length (mm): 210
• Number of modules: 6

KDB series switchgear, which meets the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

This 92x92x42mm Universal Surface-Mounted Box allows you to install flush-mounted switchgear without drilling holes in the wall.

Made from halogen-free polycarbonate (PC), this universal box is highly resistant and has pre-cut entrances for tubes, cables and trunking. Thanks to its dimensions, you can install standard-sized switchgear, so it's compatible with the majority of flush-mounted switchgear series on the market.

The 92x92x42 mm Universal Surface-mounted Box for Apparatus is generally used for indoor installations, normally exposed, of shielded tubes or trunking. A product that will certainly fulfil its purpose and allow you to add sockets or switches to any surface, for example.

* Fixing screws included.

Supply voltage: 220-240V AC 50/60Hz
Number of sockets: 4
Maximum load: 13A
Maximum power: 3000W
Overvoltage protection: 1500V
Protection level: IP20
Cable marking: H05VV-F, 3X1.5mm2, 0.2mm
Cable sheath material: PVC
Length: 5.0 [m]

• Dimensions:
• Height (mm): 160
• Width (mm) : 65
• Length (mm): 160
• Number of modules: 8

DB series switching devices, which meet the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Height (mm): 200
• Width (mm) : 95
• Length (mm): 147
• Number of modules: 6

DB series switching devices, which meet the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Height (mm): 204
• Width (mm): 102
• Length (mm): 194
• Number of modules: 6

Series KDB switchgear, which meets the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000

Supply voltage: 110-250 V AC 50/60 Hz
Maximum load: 10 A
Maximum power: 2,500 W
Overvoltage protection: 1,500 V
Number of 230 V sockets: 5
Protection level: IP22
Cable marking: H05VV-F, 3X1.0 mm2,
sheath 0.2 mm Cable material: PVC
Housing material: ABS
Length: 2.0 [m]:
Switch: Yes, for each socket separately

Digital daily/weekly clock with LCD display ideal for swimming pool treatment plants, irrigation, etc.

Ready for DIN rail installation, it has a 230V AC power supply, 16 A / 250V AC switching capacity, maximum recommended load of 2000W, minimum interval of 1 minute and open contact (NO).

It supports up to 16 different programmes per day or week with a maximum of 18 steps per programme and pulses from 1 minute to 1 hour. It counts down from 100 minutes and has a 15-day reserve and a connection cable capacity of up to 2.5 mm².

Complies with international standards EN / IEC60730-1 and CE & RoHS certificates.

* Caution: When using for the first time, you must press the "RESET" button to switch the display on.

Supply voltage: 110-250V AC 50/60Hz
Maximum load: 10A
Maximum power: 2500W
Overvoltage protection: 1500V
Number of 230V sockets: 5
Type of sockets: Schuko
Number of USB 5V 2A sockets: 4x USB-A + 1x USB-C
Protection level: IP22
Cable marking: H05VV-F, 3X1.0 mm2, 0.2 mm
Cable sheath material: PVC
Housing material: ABS
Length: 2.0 [m]:
Switch: Yes, for each socket separately

• Dimensions:
• Height (mm): 130
• Width (mm) : 60
• Length (mm): 86
• Number of modules: 4

DB series switching devices, which meet the requirements for resistance to embers at 650°C, may only be used on non-combustible surfaces (e.g. solid, solid walls made of non-combustible materials). They may not be used on flammable surfaces (e.g. plasterboard, wood, etc.), hollow walls or electrical conduits.

• Dimensions:
• Width (mm): 19
• Length (mm) : 20000
