A single-phase track is a lighting system that allows luminaires to be installed and moved along a single track fed by a single electrical phase. This type of track is often used in commercial and residential environments to offer maximum lighting flexibility.
Subcategories
There are 38 products.
This cover for your Nordlux Link system can be adjusted to fit the gaps between your luminaires.
This cover for your Nordlux Link system can be adjusted to fit the gaps between your luminaires.
Bulb not included.
Rondie features a classic, round design with a frosted glass ring that adds an interesting lighting effect to the design. It emits a pleasant, directional light. Easy to install and adjust thanks to the ‘ Nordlux Link’ system.
Double adapter for electrical connection between two rails.
This multi-socket from the Nordlux Link system is 1 metre long and can be fixed to the wall or ceiling. Allows you to quickly and easily fit Link suspended and recessed spotlights according to your own requirements. Electrical adapter included.
Adapter for reverse current electrical connection, transmission of current between different rails, etc.
Swivel adapter for coupling two rails. Continuously swivels from 7 to 290 degrees.
Double adapter for electrical connection between two rails.
Black lacquered aluminium rail
Total dimensions (with accessories): 2,000 x 42 x 20 [ mm]
Power supply: 100-240 V AC 50/60 Hz
Number of phases: 1 (two wires)
Material: Aluminium + copper conductors
Luminaire colour: White
Application: Surface mounting
Maximum power: 1,000 W
Overall dimensions (with accessories): 2,000 x 34 x 19 [mm]
Track dimensions: 1 921 x 34 x 19 [mm]
Resistance class: IP20
Operating temperature : -25 °C + 60 °C
Accessories included: End cap + supply terminal
This multi-socket from the Nordlux Link system is 1.8 metres long and can be mounted on the wall or ceiling. Allows you to quickly and easily fit Link suspended and recessed spotlights according to your own requirements. Electrical adaptor included.
White connector for connecting several Link system supply rails. The connector fits into the ends of the rails to extend the rail.
This multi-socket from the Nordlux Link system is 1.8 metres long and can be mounted on the wall or ceiling. Allows you to quickly and easily fit Link suspended and recessed spotlights according to your own requirements. Electrical adaptor included.
| Power | Temperature | Lumens |
| 30W | CCT | 3000 |
| Angle | Voltage | Protection IP |
| 24-60º | 230V | 20 |
| Dimmable | Dimensions: | |
| No | Ø 90mm | |
| Power | Voltage | Angle | Dimmable |
| 12W | 220/240V AC | 24° | No |
| Temperature | Lumens | ||
| 4500K | 1200 | ||
| Dimensions (Ø x H) | Ø 90 x 205 mm |
| Adjustable | Yes |
| IP rating | 20 |
Power supply: 100-240V AC 50/60Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + Copper conductors
Colour: Black
Resistance class: IP20
Application: Plug-in rail mounting
Type: I
Overall dimensions: 78 x 35 x 18 [mm]
Operating temperature : -25° + 60°C
Power supply: 100-240V AC 50/60Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + Copper conductors
Colour: White
Resistance class: IP20
Application: Plug-in rail mounting
Type: I
Overall dimensions: 78 x 35 x 18 [mm]
Operating temperature : -25° + 60°C
Power supply: 100-240V AC 50/60Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + Copper conductors
Colour: Black
Resistance class: IP20
Application: Pressed rail mounting
Type : L
Overall dimensions : 109 x 109 x 17 [mm]
Operating temperature : -25° + 60°C
Power supply: 100-240V AC 50/60Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + Copper conductors
Colour: White
Resistance class: IP20
Application: Pressed rail mounting
Type : L
Overall dimensions: 109 x 109 x 17 [mm]
Operating temperature : -25° + 60°C
Spotlight with GU10 socket.
Spotlight with GU10 socket.
This multi-socket from the Nordlux Link system is 1 metre long and can be fixed to the wall or ceiling. Allows you to quickly and easily fit Link suspended and recessed spotlights according to your own requirements. Electrical adapter included.
White connector for connecting several Link system supply rails. The connector fits into the ends of the rails to extend the rail.
Swivel adapter for coupling two rails. Continuously swivels from 7 to 290 degrees.
Spotlight with GU10 socket.
Power supply: 100-240 V AC 50/60 Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + copper conductors
Colour: Black
Resistance class: IP20
Application: Press-fit to rail
Type: T
Overall dimensions: 106 x 70.6 x 17 [mm]
Operating temperature : -25° + 60°C
Power supply: 100-240 V AC 50/60 Hz
Number of phases: 1 (two wires)
Material: Metal + ABS + copper conductors
Colour: White
Resistance class: IP20
Application: Press-fit to rail
Type: T
Overall dimensions: 106 x 70.6 x 17 [mm]
Operating temperature : -25° + 60°C
